The Reference Architecture Model for Industry 4.0 (RAMI 4.0) provides a comprehensive framework for developing smart manufacturing systems. Rather than defining specific technologies, RAMI 4.0 establishes a structure for understanding how different Industry 4.0 components, standards, and technologies fit together. This tutorial explains the three-dimensional RAMI 4.0 model and how it guides digital transformation in manufacturing.

Understanding RAMI 4.0 is essential for architects, engineers, and managers planning Industry 4.0 implementations that integrate legacy systems with modern technologies.

‍

‍

The Purpose of RAMI 4.0

‍

RAMI 4.0 creates a manageable architecture that serves as a frame of reference for Industry 4.0 application development. It helps organizations:

• Identify and position existing standards within the Industry 4.0 context
• Find gaps where standards don't exist
• Discover overlaps where multiple standards address the same concerns
• Plan integration strategies for new and legacy systems

‍

Building on Legacy Systems

While building smart factories from scratch would be ideal, reality demands different approaches. Most Industry 4.0 development happens on top of existing legacy manufacturing systems. RAMI 4.0 acknowledges this by expanding on ISA-95 (IEC 62264), the international standard that defines how most legacy manufacturing facilities are implemented.

Traditional manufacturing systems use a pyramidal network and system architecture based on ISA-95, which defines an automated interface between enterprise and control systems. RAMI 4.0 extends this foundation to accommodate smart manufacturing capabilities.

‍

The Three-Dimensional Model

‍

RAMI 4.0 takes all crucial aspects of Industry 4.0 and combines them into a three-dimensional model. This approach breaks down complex interrelations across domains into smaller, simpler clusters.

The three dimensions are:

1. Hierarchy Levels: Where components live in the organizational structure
2. IT Layers: The internal architecture and capabilities of components
3. Lifecycle and Value Streams: How components evolve from concept to retirement

‍

Why Three Dimensions Matter

‍

Consider a pump in a factory. The hierarchy level dimension tells us it lives at the field device level of the manufacturing facility. But we also need to define layers within the pump itself—its physical properties, communication abilities, and integration capabilities. This requires a separate dimension for IT layers.

Similarly, the pump goes through a lifecycle from initial concept through manufacturing, installation, operation, and eventual decommissioning. This lifecycle with its associated value streams needs its own dimension for proper tracking.

This three-dimensional model enables organizations to identify existing standards for each layer on each axis, find gaps requiring new standards, close loopholes in current standards, and identify overlapping standards that might cause confusion.

‍

Hierarchy Levels Dimension: Vertical Integration

The hierarchy levels dimension provides vertical integration guidance within factories. It describes criteria for assigning factory assets within levels of a manufacturing organizational hierarchy.

‍

ISA-95 Foundation with Extensions

‍

RAMI 4.0 uses ISA-95 hierarchy levels as its foundation but extends them to reflect Industry 4.0 capabilities:

Traditional ISA-95 Levels:

• Enterprise level
• Site level
• Area level
• Work cell level
• Control level
• Field device level

RAMI 4.0 Additions:

Product (Bottom): Added to capture the concept of smart products. In Industry 4.0, manufactured products are intelligent and may contain functionality during production, influencing the production process itself.

Connected World (Top): Added to signify links to the world outside the factory. Industrial IoT enables connections between different manufacturing facilities within an organization or extends beyond enterprise boundaries to engineering firms, customers, and suppliers.

‍

Network vs Pyramid Architecture

‍

Traditional pyramidal architectures restrict communication—components only talk to others at adjacent levels. RAMI 4.0 enables components to connect with other components from any level, forming a network-structured architecture.

This network structure sets the stage for smart manufacturing. Components gather information from others at any level and autonomously reconfigure, adapt, and optimize themselves accordingly. However, this only works with consistent information representation—ERP systems and field-level sensors must represent information the same way.

‍

IT Layers Dimension: Component Architecture

‍

The IT layers dimension represents the architecture of individual components within a manufacturing facility. A component can be anything represented in the production process—physical machines, software applications, documents, or human beings.

RAMI 4.0 decomposes component architecture into six layers:

‍

Asset Layer

The asset layer represents physical properties—metal parts, circuit diagrams, QR codes, documentation, and other tangible characteristics of the component.

‍

Integration Layer

The integration layer provides information about the component in a digitally processable form so it can integrate with other components. In Industry 4.0, this typically manifests as a digital twin.

The Asset Administration Shell is a key standard at this layer. Through the integration layer, components that cannot communicate for themselves—fully mechanical components or human beings—can participate in the information world via human-machine interfaces.

‍

Communication Layer

The communication layer provides standardized methods for communicating digital information about components using common data formats and predefined protocols. It provides services to the integration layer.

OPC UA is one of the most common standards used at this layer, enabling interoperable communication between different vendor systems.

‍

Information Layer

The information layer processes data about components, persists it onto well-defined information models to ensure data integrity, and makes it available as useful information via service interfaces.

This layer enforces semantic interoperability, making data representation and access Industry 4.0 compatible. It ensures different systems interpret the same data the same way.

‍

Functional Layer

The functional layer includes formal descriptions of functions or services the component provides to other components in smart manufacturing systems. It incorporates decision-making logic, executes services supporting business processes, and serves as the basis for remote access and horizontal integration.

The functional layer provides Industry 4.0 compatible functional access to components. ERP functions in manufacturing contexts typically reside at this layer.

‍

Business Layer

The business layer defines which manufacturing business processes the component links to and what legal and regulatory conditions it operates under. This top layer connects components to business objectives and compliance requirements.

‍

Lifecycle and Value Streams Dimension

‍

The lifecycle and value streams dimension represents the lifespan of Industry 4.0 components. A component could be a product, a machine, or an entire factory.

This dimension provides a standardized approach to describe and track components over their entire lifetime from conceptualization through usage, maintenance, and decommissioning.

‍

IEC 62890 Foundation

RAMI 4.0 borrows from IEC 62890, a standard establishing basic principles for lifecycle management of systems and components used in industrial systems.

‍

Types vs Instances

A critical distinction exists between component types and instances:

Type: The description of a product or machine in its basic idea before creation, existing as documents or digital models. Created during conceptualization.

Instance: An individual physical copy of a component manufactured from the type description. Results from the manufacturing process using the type description as input.

As instances encounter the real world, usage and maintenance information is generated and fed back to the type stage, enabling improvements to the concept.

‍

Interconnected Lifecycles Example

Consider a machine parts manufacturer:

1. Parts Manufacturer: Describes a part type, manufactures parts, and delivers them to a machine manufacturer. The delivered parts become instances.
2. Machine Manufacturer: Describes a machine type, assembles part instances, manufactures machines, and delivers machine instances to a factory.
3. Factory Operator: Describes a product type, uses machine instances to manufacture products, and delivers product instances to end users.
4. Feedback Loop: During machine usage, information about specific parts is generated and relayed back to the parts manufacturer, who updates the part type so new instances incorporate improvements.

Types also have development, usage, and maintenance stages just as physical instances do. RAMI 4.0 treats types and instances as separate but equivalent entities.

‍

Value Chain Perspective

Due to these interconnected lifecycles from various stakeholders, Industry 4.0 component lifecycles cannot be viewed in isolation. They represent a collective involving all parties from component suppliers to end customers.

RAMI 4.0's goal with this dimension is identifying standards that establish relationships between types and instances across the entire manufacturing value chain.

‍

Mapping Industry 4.0 Components

Within these three dimensions, all crucial aspects of Industry 4.0 can be mapped. Industry 4.0 components—sensors, machines, factories—are classified according to the model, making it possible to describe and implement highly flexible systems with step-by-step transitions from traditional manufacturing to smart manufacturing.

‍

Benefits of the RAMI 4.0 Framework

‍

Unified Perspective Across Disciplines

RAMI 4.0 provides everyone in the smart manufacturing ecosystem a unique perspective with a unified approach—whether working in IT, industrial automation, or equipment manufacturing.

‍

Standards Identification

Organizations can systematically identify which standards apply at each intersection of hierarchy level, IT layer, and lifecycle stage.

‍

Gap Analysis

The framework reveals where standards are missing, enabling focused development of new standards where needed most.

‍

Overlap Resolution

When multiple standards address the same concerns, RAMI 4.0 helps identify overlaps and select appropriate options.

‍

Integration Planning

The model guides integration strategies, showing how new Industry 4.0 technologies connect with existing legacy systems at specific levels and layers.

‍

Summary

RAMI 4.0 provides a comprehensive three-dimensional framework for understanding and implementing Industry 4.0 systems. The hierarchy levels dimension addresses vertical integration and organizational structure. The IT layers dimension defines component architecture from physical assets through business processes. The lifecycle and value streams dimension tracks components from concept through retirement while distinguishing between types and instances.

This framework enables systematic classification of Industry 4.0 components, identification of applicable standards, and planning of gradual transitions from traditional manufacturing to smart manufacturing. By providing a common reference model, RAMI 4.0 helps diverse stakeholders across IT, OT, and business domains work together toward unified Industry 4.0 implementations.

‍
